G TRAIL 2.0

Choose Colour

Frame shape

Frame

Wheels

29"/622mm

Frame Geometries

Geometries G TRAIL 2.0

Size

A Top Tube Length B Seat Tube Length C Seat Tube Angle D Head Tube Length E Steering Angle F Chain Stay Length G Wheel Base H Standover Height I BB-Drop J Stack K Reach L Stem Length M Crank Length

Size

A Top Tube Length B Seat Tube Length C Seat Tube Angle D Head Tube Length E Steering Angle F Chain Stay Length G Wheel Base H Standover Height I BB-Drop J Stack K Reach L Stem Length M Crank Length

Size

A Top Tube Length B Seat Tube Length C Seat Tube Angle D Head Tube Length E Steering Angle F Chain Stay Length G Wheel Base H Standover Height I BB-Drop J Stack K Reach L Stem Length M Crank Length

592 mm 440 mm 74 ° 125 mm 65.5 ° 475 mm 1252 mm - 28 mm 642 mm 450 mm 35 mm 165 mm

618 mm 470 mm 74 ° 130 mm 65.5 ° 475 mm 1276 mm - 28 mm 647 mm 475 mm 35 mm 165 mm

645 mm 500 mm 74 ° 140 mm 65.5 ° 475 mm 1308 mm - 28 mm 656 mm 500 mm 35 mm 165 mm

Unisex Frame

Get out and hit it

Base Price

45 990,00 SEK 51 990,00 SEK

Save 6000 SEK!

On Sale until 31.07.24

Calculate size

Specifications

Wheel size 29"/622mm
Frame 29", Alloy 6061, Integrated battery, Boost, 150 mm
Fork RockShox Revelation RC, DebonAir, Air, 150 mm, tapered
Shock RockShox Deluxe Select+, Air, 230x65 mm
Motor Yamaha PW-ST, 250 W, 70 Nm
Battery Simplo, 630 Wh, 36 V
Display Yamaha Display A, LCD-Display
Rear derailleur SRAM SX Eagle, 12-S
Front brake Magura MT5, 4-piston, Hydraulic disc brake
Crank arm GASGAS EC40, Aluminum forged, JIS

Frame 29", Alloy 6061, Integrated battery, Boost, 150 mm
Fork RockShox Revelation RC, DebonAir, Air, 150 mm, tapered
Shock RockShox Deluxe Select+, Air, 230x65 mm
Motor Yamaha PW-ST, 250 W, 70 Nm
Battery Simplo, 630 Wh, 36 V
Charger Simplo rapid charger, 4 A
Mode Switch Integrated into display
Display Yamaha Display A, LCD-Display
Front brake Magura MT5, 4-piston, Hydraulic disc brake
Front brake rotor Magura MDR-C, 203 mm, 6-hole
Rear brake Magura MT5, 4-piston, Hydraulic disc brake
Rear brake rotor Magura MDR-C, 180 mm, 6-hole
Rear derailleur SRAM SX Eagle, 12-S
Cassette SRAM PG-1210, 11-50 T
Chain SRAM SX Eagle
Chainring GASGAS, Narrow Wide, 38 T
Crank arm GASGAS EC40, Aluminum forged, JIS
Shift lever SRAM SX Eagle, Single Click
Front wheel Rim: Mach 1 TRUCKY 30, With eyelets, Tubeless ready / Hub: GASGAS DA210F, 6-hole, 15x110 mm, thru axle
Rear wheel Rim: Mach 1 TRUCKY 30, With eyelets, Tubeless ready / Hub: GASGAS DA210R, 6-hole, 12x148 mm, thru axle
Tire Schwalbe Nobby Nic, Evolution, 62-622, 29, 2.4, Tubeless ready
Stem GASGAS 31,8, 0 °, Ahead
Headset GASGAS ZS44/ZS56
Handlebar GASGAS Riser 31.8 mm, 780 mm, Sweep: 9 °, Rise: 15 mm
Grips GASGAS MTB, Lock-on grips
Saddle GASGAS MTB
Seat post GASGAS, 31.6 mm, Dropper post
Pedals GASGAS, aluminum
Chain guide Direct Mount
Weight 25.5 kg
Permissible total weight 130 kg
Trailer approval No trailer approval
STVZO konform STVZO No

Due to problems in supply chain, the bike can be delivered with modifications.
